Getting Started with Medical Image Classification Using Deep Learning

Introduction

Medical image classification is one of the most accessible entry points into healthcare AI. The core task, given a medical image, assign it a diagnostic category, is structurally identical to standard image classification. The difference is that the stakes are higher and the failure modes are more subtle. A misclassified cat is a meme. A misclassified pathology slide is a missed diagnosis.

This tutorial walks through building a medical image classifier using PyTorch. It draws from my experience building Histia, a pathology AI system, and focuses on the practical decisions that separate a working medical classifier from a dangerously misleading one. If you know basic Python and have seen a PyTorch tutorial, you have enough to follow along.

Choosing Your Dataset

The dataset determines everything downstream. For a first project, you want something small enough to iterate quickly, well-labeled enough to trust, and medically relevant enough to be interesting.

Start with PathMNIST. Part of the MedMNIST collection, it provides standardized 224x224 images with consistent train/val/test splits, eliminating data engineering overhead so you can focus on modeling.

from medmnist import PathMNIST
from torchvision import transforms

train_transform = transforms.Compose([
    transforms.Resize(224),
    transforms.RandomHorizontalFlip(),
    transforms.RandomVerticalFlip(),
    transforms.RandomRotation(15),
    transforms.ToTensor(),
    transforms.Normalize(mean=[0.485, 0.456, 0.406], std=[0.229, 0.224, 0.225])
])
val_transform = transforms.Compose([
    transforms.Resize(224),
    transforms.ToTensor(),
    transforms.Normalize(mean=[0.485, 0.456, 0.406], std=[0.229, 0.224, 0.225])
])

train_data = PathMNIST(split="train", transform=train_transform, download=True, size=224)
val_data = PathMNIST(split="val", transform=val_transform, download=True, size=224)
test_data = PathMNIST(split="test", transform=val_transform, download=True, size=224)

Preprocessing Pitfalls Specific to Medical Imaging

Medical image preprocessing has domain-specific pitfalls that general CV tutorials never cover.

Transfer Learning: The Two-Phase Approach

Do not train from scratch. Medical image datasets are small by deep learning standards. Transfer learning is not optional. It is required. ResNet-50 pretrained on ImageNet is the baseline: well-understood, fast to fine-tune, and competitive on most medical imaging benchmarks.

import torch
import torch.nn as nn
from torchvision.models import resnet50, ResNet50_Weights
from torch.optim import AdamW

class MedicalClassifier(nn.Module):
    def __init__(self, num_classes=9, freeze_backbone=True):
        super().__init__()
        self.backbone = resnet50(weights=ResNet50_Weights.IMAGENET1K_V2)
        if freeze_backbone:
            for param in self.backbone.parameters():
                param.requires_grad = False
        in_features = self.backbone.fc.in_features
        self.backbone.fc = nn.Sequential(
            nn.Dropout(0.3), nn.Linear(in_features, 512), nn.ReLU(),
            nn.Dropout(0.2), nn.Linear(512, num_classes)
        )

    def forward(self, x):
        return self.backbone(x)

    def unfreeze(self):
        for param in self.backbone.parameters():
            param.requires_grad = True

model = MedicalClassifier(num_classes=9, freeze_backbone=True).cuda()
criterion = nn.CrossEntropyLoss()

# Phase 1: Train classifier head (5-10 epochs, lr=1e-3)

opt = AdamW(model.backbone.fc.parameters(), lr=1e-3, weight_decay=1e-4)

# Phase 2: Unfreeze and fine-tune entire network (10-20 epochs, lr=1e-5)

model.unfreeze()
opt = AdamW(model.parameters(), lr=1e-5, weight_decay=1e-4)

Phase one freezes the backbone and trains only the classification head at lr=1e-3, adapting the classifier to your label space without disrupting pretrained features. Phase two unfreezes the backbone and fine-tunes at lr=1e-5, letting the feature extractor adapt to medical image statistics while the classifier head stays stable.

Vision Transformers (ViT) often outperform CNNs on medical imaging because their attention mechanism handles spatial relationships between tissue structures naturally. But they are more data-hungry. Try ViT-B/16 after you have a ResNet baseline. If ViT does not improve AUROC by at least 2 points, the complexity is not worth it.

Evaluation: Why Accuracy Lies

Here is where most tutorials fail. In medical classification, accuracy is a misleading metric. A skin lesion classifier where 95% of images are benign achieves 95% accuracy by predicting "benign" for everything while missing every cancer case.

from sklearn.metrics import roc_auc_score, classification_report
import numpy as np

def evaluate(model, loader, device):
    model.eval()
    all_probs, all_labels = [], []
    with torch.no_grad():
        for images, labels in loader:
            outputs = model(images.to(device))
            all_probs.append(torch.softmax(outputs, dim=1).cpu().numpy())
            all_labels.append(labels.squeeze().numpy())
    probs, labels = np.concatenate(all_probs), np.concatenate(all_labels)
    auroc = roc_auc_score(labels, probs, multi_class="ovr", average=None)
    print(f"Mean AUROC: {auroc.mean():.4f}")
    print(classification_report(labels, probs.argmax(1), digits=4))

Common Pitfalls That Waste Months

Conclusion

Building a medical image classifier is structurally similar to any image classification task. The difference is that every decision carries clinical weight. Random color jitter destroys diagnostic signal. Accuracy hides class imbalance. Image-level splits produce unreplicable results.

Start with PathMNIST and a pretrained ResNet-50. Get the two-phase transfer learning pipeline working. Evaluate with AUROC and per-class metrics. Split at the patient level. Then iterate. The goal is not to beat a benchmark. It is to build something a clinician would trust with their patients, and that standard is much higher and more interesting than a leaderboard position.
